SO-CONNECT +
Pump

SO-CONNECT+ subcutaneous immunoglobulin infusion pump

Scroll for more

SO-CONNECT+ subcutaneous immunoglobulin infusion pump

SO-CONNECT+ subcutaneous immunoglobulin infusion pump | 01

The SO-CONNECT+ pump is an ambulatory infusion pump dedicated to controlled subcutaneous administration of SC-ig and Desferal

It uses 20, 30 and 50mL single-use drug biocompatible sterile syringe SO-FILL exclusively. One SO-CONNECT+ pump is compatible with all these syringe volumes.

Healthcare professionals in a clinical environment and users (patient or medical staff) at home are using the SO-CONNECT+ pump.

20mL

30mL

50mL

Ensure patient safety

Product | 02

The SO-CONNECT+ pump is intended to simplify treatment and ensure patient safety

User-friendly

With a touchscreen

Telehealth

Via Bluetooth connection for the transmission of clinical data

Safe

with a display lock for settings and configurations

Smart

via simplified infusion management that allows the modification of the flowrate even during infusion.
SO-CONNECT+ immunoglobulin pump zoom

One pump, three syringe volumes

Click for more

syringe SO-FILL 20ml for SO-CONNECT immunoglobulin  pump

20mL

syringe  SO-FILL 30ml for SO-CONNECT+ immunoglobulin   pump

30mL

syringe SO-FILL 50ml  for SO-CONNECT+ immunoglobulin  pump

50mL

SO-CONNECT+ subcutaneous immunoglobulin infusion pump for Immunoglobulin and Deferoxamine therapy | 03

Information

Set up patient information

Multiple flowrates

Wide range of flowrates going from 0.5 mL/h to 300mL/h by increments of 0.1mL/h

Monitoring

Declare undesirable effects during the infusion

Programmable

Programmable volumes from 1 to 600mL

Mode

Set up either the duration or the flowrate (the pump calculates the other parameter)

Priming

No automatic priming function (in compliance with SPC)

SO-CONNECT+ subcutaneous immunoglobulin infusion pump – Safety first | 04

Syringe

Drug-biocompatible syringe (COC Topas)

Alarm system

Comprehensive alarm system compliant with regulations

Syringe detection

Syringe detection with a switch

Needle

Draw-off needle included

Occlusion

Optimized occlusion detection

Security

Display lock (with password) to prevent misuse
SO-CONNECT+ immunoglobulin pump waiting for SO-FILL syringes

In the box | 05

1 SO-CONNECT + pump   /   2 batteries   /   1 charger   /   The IFU

The box of SO-CONNECT+ immunoglobulin  pump

Accessories | 06

SO-CONNECT + simulator for educational purposes

SO-SIM software for SO-CONNECT+ immunoglobulin pump

Syringe fill tool

SO-EASY tool for syringe SO-FILL immunoglobulin

Protective case

SO-MOVE - protective case for SO-CONNECT+ immunoglobulin   pump

Documents | 07

Click for more

About SO-CONNECT +

TitleVersionDate addedDownload
IFU (EN) - SO-CONNECT PLUS 1.05.0106-10-2020 Preview
Technical marketing doc (EN) - SO-CONNECT PLUS 1.003-05-2021 Preview

Certifications

TitleVersionDate addedDownload
Marquage CE 1.025-11-2022 Preview
ISO 13485 v2016 rev 4 4.025-11-2022 Preview
The ambulatory infusion pump SO-CONNECT+ is manufactured by F.D.E. It is a medical device that subcutaneously infuses immunoglobulins and deferoxamine. The notified body GMED concluded that the product SO-CONNECT+ complies with regulations. It holds the CE mark number 32586. Carefully read all instructions prior to use.
